KIENINGER RWU-03 9 CHIME BELL SPRING WOUND MOVEMENT
Kieninger RWU-03 is a cable driven two-spring wind movement (two weights) with an 65cm pendulum. 1/4 cable/key wind movement with triple chime (Westminster, St. Michael, and Whittington) on 9 bell chime. The rear hammers are in an 8 x 1 configuration. Four or six bronze bushings (2nd wheel), removable spring barrels, and chime shut-off.
Plate size: 131 x 131 x 2.0mm. Hand shaft length 48mm.
9 brass bells are not included.
The movement supports a recommended lyre or grid or wood stick or metal rod style pendulum. The lyre pendulum bob should be 165mm (6 1/2"), the grid pendulum bob should be 140mm (5 1/2") diameter, and if a wood stick pendulum the bob should be 140mm (5 1/2") or 115mm (4 1/2") or 100mm (4"). Also supported is a metal rod pendulum with a bob at 80mm (3.14").
This movement was used by many clock manufacturers such as Sligh and Howard Miller.
Movement is New Old Stock (NOS) and does not come with a manufacturer warranty. Recommend German made Etsyntha 859 lubrication prior to installation.
Made in Germany.
