PLATFORM ESCAPEMENT 18MM X 28MM WITH 11 JEWELS SWISS
For French, English, and German clocks. Plate size: .71" (18mm) x 1.1" (28mm). The escape wheel turns clockwise as viewed from the top.
Top of plate to pinion tube housing: 7.89mm. Bottom of plate to pinion tube housing: 5.90mm. The pinion brass tube is 4.4mm dia.
18,000 BPH, 11 jewels, KIF device on balance cock. Friction fit potence (the protective cover for the escape pinion) that can be turned allowing more access to the contrate wheel. 8 leaf escape pinions.
Please note: Supplied without mounting holes and must be fitted to clock.
No returns on platform escapements.
Made in Switzerland.
